DA-PWR-200 Power Module Series
Power modules for the DA-920E Series
Features and Benefits
- Isolated power supply
- Hot-swappable
- -40 to 85°C wide operating temperature
Introduction
The DA-PWR-200 power module Series comprises of isolated, hot-swappable power modules specifically engineered for the Moxa DA-920E Series industrial computers. These versatile power modules enable compatible systems to utilize a wide input power range of 100 to 240 VAC/ VDC and 24 to 110 VDC. In additon, they are designed to operate in a wide operating temperature range of -40 to 85°C, ensuring consistent and reliable performance.
Models in this series (2)
| — | DA-PWR-200-HV | DA-PWR-200-WV | — | — |
| Input Voltage | 100 to 240 VAC, 50 to 60 Hz 100 to 240 VDC | 24 to 110 VDC | ||
| Operating Voltage | 90 to 264 VAC, 50 to 60 Hz 90 to 264 VDC | 21.6 to 121 VDC | ||
| Supported Series | DA-920E Series | DA-920E Series | ||
| — | Add to Quote View Bag | Add to Quote View Bag |
Specifications
Shown for DA-PWR-200-HV. Per-model differences are listed in the selection grid above.
Power Parameters
- Input Voltage
- DA-PWR-200-HV: 100 to 240 VAC/VDC DA-PWR-200-WV: 24 to 110 VDC
- Operating Voltage
- DA-PWR-200-HV: 90 to 264 VAC/VDC DA-PWR-200-WV: 21.6 to 121 VDC
- Overload Current Protection
- Supported
- Overload Voltage Protection
- Supported
- Overload Temperature Protection
- Supported
Physical Characteristics
- Weight
- DA-PWR-200-HV: 820g (1.8 lbs) DA-PWR-200-WV: 820g (1.8 lbs)
Environmental Limits
- Operating Temperature
- -40 to 85°C (-40 to 185°F)
MTBF
- Time
- DA-PWR-200-HV: 3,886,750 hrs DA-PWR-200-WV: 3,227,791 hrs
- Standards
- Telcordia SR-332 Standard Issue 4
Warranty
- Warranty Period
- 3 years
- Details
- See www.moxa.com/warranty
